| Power | 0.75 KW |
| Horsepower | 1 HP |
| No. of Poles | 4 Pole |
| Mounting Type | Flange |
| Brand | S.V TRANSMISSION |
| No of Phase | Single Phase |
| Phase | Single Phase |
| Rated Power | 3 hp, 1.25-2 hp, 2.25-3 hp, 0.5-1 hp |
Range :0.10 H.P. to 20 H.P. (0.075 K.W. to 15 K.W.) Frame 63 to 160L in 2, 4, 6, & 8 Pole
Mounting: Foot – Flange – Face
Standards: Performance conforms to be: 325 and dimensions according to IS 1231 & IS 2223
Frame: Motor are supplied in a robust, rugged cast iron frame with integral feet. On Request, we can supply motor in aluminium body up to 100 L frame.
Ratings: All Standard Three-phase Motors are continuous rated to comply with performance standards.
Voltage and Frequency: Supply volts 415 +- 5% 3 phase 50 Hz. +- 3% (on customer request we are also able to supply motor in 220, 380, 460, 525 volts on HZ. 50 or 60 Also)
Enclosures: Motor IP-44 Protection as defined in IS: 4691. Motors can be supplied with IP-54 and IP-55 on request.
Additional Information:
Country of OriginMade in IndiaTorque (KGCM)10 KGCMIP RatingIP40Voltage230 VWeight5-10 KgCurrent in Ampere0-10 AP.F0.7-0.... Continue
Power1.1 KWHorsepower3 HPType of Induction MotorsSingle Phase Induction MotorsSpeed1000 ... Continue
Power1 hpType of Induction MotorsSingle Phase Induction MotorsTypeSingle Phase Electric MotorIP RatingIP23Speed750 RPMPo... Continue
Power :2.6-5 hpMaterialCast IronRated Power... Continue
